WINDOW FRAME CUTTING MACHINE RV70U

( VIRUTEX )

Virutex



Ask a question about this product

WINDOW FRAME CUTTING MACHINE

RV70U

RV70S_

RV70S_2
Carbide saw blade for wood Ø200 Z30 (ref. 7040330) and diamond blade Ø 180 (ref. 7040329) for building materials as standard equipment.

RV70S_3

Standard equipment
Front square guide to trim windows, 30z MD D.200 blade to cut wood, D.180 diamond blade to cut building materials, 3 m dust collection tube and carrying case.

Optional accessories
9545854 Kit GRM70S: includes the guide and the accessories needed to turn the RV70U into a door frame trimmer.

The new RV70U trimmer is designed to cut wooden window frames and for use in restoration work or window replacement by creating slots around the frame, making it easier to extract the frame support.
For window frame cutting, the RV70U is equipped with a special saw blade of 30 hard metal teeth and an adjustable front square guide which is used as a support guide for the cut. To create slots in the frame support structure, the RV70U also comes with a diamond blade designed to cut building materials. It can even make slots in the four corners; to do this the user simply has to change the position of the machine’s reversible base to the bevelled side.
The new RV70U makes the task of replacing windows much easier while retaining the original size or even increasing it in some cases. It is also an indispensable tool for installing aluminium or wooden windows.


RV70S_4
Trimming wooden window frames. Register on the adjustable front guide square.


RV70S_5
Diamond blade for cutting building materials for the complete extraction of the frame. Register on the straight front of the reversible base.

RV70S_6
Makes cutting slots in the 4 corners easy. Register on the bevelled front of the reversible base.


SPECIFICATIONS

INPUT POWER

1700W

NO-LOAD SPEED

3300/min

MAX. CUTTING DEPTH WITH SAW BLADE

68 mm

MAX. CUTTING DEPTH DIAMOND BLADE

58 mm

HEIGHT OF THE CUT FROM THE BASE

7 mm

WEIGHT

6,7 kgs
